不同的用途与百科/Brief Introduction：

这个机器是成为原浆、油类液的玻璃钢瓶的新货品，充分处理好了往往原浆、油类液的玻璃钢瓶的不恰当的目的。该类灌封机采用的塑料材质瓶，不单不所需洗瓶机、吹干机，更不所需空气消毒，都可以一直灌封。这个机器全智能理瓶、进瓶、包装，包装量维持，无漏滴，无瓶不包装。上盖、封膜率高达100%。此机技木最新，体型大小小、程序运行维持、的噪音低，方法修理、清理简单方便等优点和缺点，基本包含GMP规则。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本规格型号有慢速和髙速两大类产品的生产数量供您会选择。Note: this model has two kinds of low speed and high-speed production for your choice.

基本特征 Characteristic

◆该设备适用性于繁多易折瓶口服药液记量罐装和封膜。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆全部设备电子器件均采用了有名品店牌。All electrical components adopt famous brand◆该设备操作流程可以直观简单方便，无瓶不装罐，测量*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折泡沫瓶子灌封机的包括构成与原因Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型内服液易折材料瓶灌封机重点理瓶器、理盖器、主齿轮传动模式、同步操作带缝隙送玻璃瓶置、玻璃瓶子检漏设备、灌装生产线系统、除去设备、具有热熔封系统、汽动设备手指头夹瓶系统、系列电机马达缝隙上瓶系统与出瓶系统等组成了。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆机气便用的冲剂液易折塑料材质瓶、盖是一个定无尘区产出的，可以有药粉材经营证，故瓶身与底盖经信息传递和"去外包服务"后可随便流入灌封间。经过理盖器、理瓶器的重新专向归置，消除方向底盖及瓶身底口朝下的瓶，使专向后的包材喂料有标准地流入运送正轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定位后服食液易折朔胶瓶在输送机轮轨总排名Directional oral liquid after folding plastic bottles in conveying rail out easily

水平性能参数technical parameters：

型号model	NLGFY-40	NLGFY-80
装量领域The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封膜率Hot sealing intensity	》99%
装量误差值The load error	《1.5%
脏污率damage rate	《1.0%
工作电压power	2KW	3KW
开关电源Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
容量 Weight	700Kg	800Kg
